Cylindrical Roller Bearing Size Chart​ in MM: Single Row, Double Row and Four Row

If you are a purchaser of cylindrical roller bearings, you may want to confirm the bearing size, check the bearing number, or see whether the bearing can fit your application.

That is why I put this cylindrical roller bearing size chart here. You can check common cylindrical roller bearing types, bearing numbers, bore diameter, outside diameter, width, load ratings, limiting speed, and other related dimensions.

This can help you compare sizes, check possible replacement models, and prepare your inquiry before purchasing.

Please note that this cylindrical roller bearing size chart is only for reference. For actual applications, you still need to confirm the bearing size, structure, clearance, precision, load capacity, and working conditions with the manufacturer before placing an order.

If you need to buy cylindrical roller bearings in bulk, you can contact BKZ Industry. With 15 years of bearing manufacturing experience, BKZ Industry can help you confirm the right bearing size, check equivalent models, and provide standard or customized cylindrical roller bearing solutions.

Now, let’s check the size chart in mm for single row, double row, and four-row cylindrical roller bearings.

Since the size chart is very long, you can press Ctrl + F on Windows or Cmd + F on Mac, then enter the bearing number or bearing size to find the model you need quickly.

Also Read: Tapered Roller Bearing Size Chart in mm: Single Row, Double Row, and Four Row Sizes

Part 1. Single Row Cylindrical Roller Bearing Size Chart

NU, NJ, NUP series

NU Type Bearing Number	NJ Type Bearing Number	NUP Type Bearing Number	Bore Diameter d (mm)	Outside Diameter D (mm)	Bearing Width B (mm)	Basic Dynamic Load Rating Cr (kN)	Basic Static Load Rating Cor (kN)	Limiting Speed with Grease Lubrication (r/min)	Limiting Speed with Oil Lubrication (r/min)	Approximate Mass W (kg)
NU 202	NJ 202	—	15	35	11	7.98	5.5	15000	19000	—
NU 203	NJ 203	NUP 203	17	40	12	9.12	7	14000	18000	—
NU 303	NJ 303	—	17	47	14	12.8	10.8	13000	17000	0.147
NU 1004	—	—	20	42	12	10.5	9.2	13000	17000	0.09
NU 204 E	NJ 204 E	NUP 204 E	20	47	14	25.8	24	12000	16000	0.117
NU 2204 E	NJ 2204 E	NUP 2204 E	20	47	18	30.8	30	12000	16000	0.149
NU 304 E	NJ 304 E	NUP 304 E	20	52	15	29	25.5	11000	15000	0.155
NU 2304 E	NJ 2304 E	NUP 2304 E	20	52	21	39.2	37.5	10000	14000	0.216
NU 1005	—	—	25	47	12	11	10.2	11000	15000	0.1
NU 205 E	NJ 205 E	NUP 205 E	25	52	15	27.5	26.8	11000	14000	0.14
NU 2205 E	NJ 2205 E	NUP 2205 E	25	52	18	32.8	33.8	11000	14000	0.168
NU 305 E	NJ 305 E	NUP 305 E	25	62	17	38.5	35.8	9000	12000	0.251
NU 2305 E	NJ 2305 E	NUP 2305 E	25	62	24	53.2	54.5	9000	12000	0.355
NU 1006	—	—	30	55	13	13	12.8	9500	12000	0.12
NU 206 E	NJ 206 E	NUP 206 E	30	62	16	36	35.5	8500	11000	0.214
NU 2206 E	NJ 2206 E	NUP 2206 E	30	62	20	45.5	48	8500	11000	0.268
NU 306 E	NJ 306 E	NUP 306 E	30	72	19	49.2	48.2	8000	10000	0.377
NU 2306 E	NJ 2306 E	NUP 2306 E	30	72	27	70	75.5	8000	10000	0.538
NU 406	NJ 406	NUP 406	30	90	23	57.2	53	7000	9000	0.73
NU 1007	—	—	35	62	14	19.5	18.8	8500	11000	0.16
NU 207 E	NJ 207 E	NUP 207 E	35	72	17	46.5	48	7500	9500	0.311
NU 2207 E	NJ 2207 E	NUP 2207 E	35	72	23	57.5	63.7	7500	9500	0.414
NU 307 E	NJ 307 E	NUP 307 E	35	80	21	62	63.2	7000	9000	0.505
NU 2307 E	NJ 2307 E	NUP 2307 E	35	80	31	87.5	98.2	7000	9000	0.738
NU 407	NJ 407	NUP 407	35	100	25	70.8	68.2	6000	7500	0.94
NU 1008	NJ 1008	—	40	68	15	21.2	22	7500	9500	0.22
NU 208 E	NJ 208 E	NUP 208 E	40	80	18	51.5	53	7000	9000	0.394
NU 2208 E	NJ 2208 E	NUP 2208 E	40	80	23	67.5	75.2	7000	9000	0.507
NU 308 E	NJ 308	NUP 308 E	40	90	23	76.8	77.8	6300	8000	0.68
NU 2308 E	NJ 2308 E	NUP 2308 E	40	90	33	105	118	6300	8000	0.974
NU 408	NJ 408	NUP 408	40	110	27	90.5	89.8	5600	7000	1.25
NU 1009	NJ 1009	—	45	75	16	23.5	23.8	6500	8500	0.26
NU 209 E	NJ 209 E	NUP 209 E	45	85	19	58.5	63.8	6300	8000	0.45
NU 2209 E	NJ 2209 E	NUP 2209 E	45	85	23	71	82	6300	8000	0.55
NU 309 E	NJ 309 E	NUP 309 E	45	100	25	93	98	5600	7000	0.93
NU 2309 E	NJ 2309 E	NUP 2309 E	45	100	36	130	152	5600	7000	1.34
NU 409	NJ 409 E	NUP 409	45	120	29	102	100	5000	6300	1.8
NU 1010	NJ 1010	—	50	80	16	25	27.5	6300	8000	0.505
NU 210 E	NJ 210 E	NUP 210 E	50	90	20	61.2	69.2	6000	7500	0.59
NU 2210 E	NJ 2210 E	NUP 2210 E	50	90	23	74.2	88.8	6000	7500	0.59
NU 310 E	NJ 310 E	NUP 310 E	50	110	27	105	112	5300	6700	1.2
NU 2310 E	NJ 2310 E	NUP 2310 E	50	110	40	155	185	5300	6700	1.79
NU 410	NJ 410	NUP 410	50	130	31	120	120	4800	6000	2.3
NU 1011	NJ 1011	—	55	90	18	35.8	40	5600	7000	0.45
NU 211 E	NJ 211 E	NUP 211 E	55	100	21	90.2	95.5	5300	6700	0.68
NU 2211 E	NJ 2211 E	NUP 2211 E	55	100	25	98.4	118	5300	6700	0.81
NU 311 E	NJ 311 E	NUP 311 E	55	120	29	128	138	4800	6000	1.53
NU 2311 E	NJ 2311 E	NUP 2311 E	55	120	43	190	228	4800	6000	2.28
NU 411	NJ 411	NUP 411	55	140	33	128	132	4300	5300	2.8
NU 1012	NJ 1012	—	60	95	18	38.5	45	5300	6700	0.48
NU 212 E	NJ 212 E	NUP 212 E	60	110	22	89.8	102	5000	6300	0.86
NU 2212 E	NJ 2212 E	NUP 2212 E	60	110	28	122	152	5000	6300	1.12
NU 312 E	NJ 312 E	NUP 312 E	60	130	31	142	155	4500	5600	1.87
NU 2312 E	NJ 2312 E	NUP 2312 E	60	130	46	212	262	4500	5600	2.81
NU 412	NJ 412	NUP 412	60	150	35	155	162	4000	5000	3.4
NU 1013	NJ 1013	—	65	100	18	39	46.5	4800	6000	0.51
NU 213 E	NJ 213 E	NUP 213 E	65	120	23	102	118	4500	5600	1.08
NU 2213 E	NJ 2213 E	NUP 2213 E	65	120	31	142	180	4500	5600	1.48
NU 313 E	NJ 313 E	NUP 313 E	65	140	33	170	188	4000	5000	2.31
NU 2313 E	NJ 2313 E	NUP 2313 E	65	140	48	235	285	4000	5000	3.34
NU 413	NJ 413	NUP 413	65	160	37	170	178	3800	4800	4
NU 1014	NJ 1014	—	70	110	20	47.5	57	4800	6000	0.71
NU 214 E	NJ 214 E	NUP 214 E	70	125	24	112	135	4300	5300	1.2
NU 2214 E	NJ 2214 E	NUP 2214 E	70	125	31	148	192	4300	5300	1.56
NU 314 E	NJ 314 E	NUP 314 E	70	150	35	195	228	3800	4800	2.63
NU 2314 E	NJ 2314 E	NUP 2314 E	70	150	51	260	320	3800	4800	4.1
NU 414	NJ 414	NUP 414	70	180	42	215	232	3400	4300	5.9
NU 1015	NJ 1015	—	75	115	20	51.5	61.2	4500	5600	0.74
NU 215 E	NJ 215 E	NUP 215 E	75	130	25	125	155	4000	5000	1.32
NU 2215 E	NJ 2215 E	NUP 2215 E	75	130	31	155	205	4000	5000	1.64
NU 315 E	NJ 315 E	NUP 315 E	75	160	37	228	260	3600	4500	3.43
NU 2315 E	NJ 2315 E	NUP 2315 E	75	160	55	245	308	3600	4500	5.4
NU 415	NJ 415	NUP 415	75	190	45	250	272	3200	4000	7.1
NU 1016	NJ 1016	—	80	125	22	59.2	77.8	4300	5300	1
NU 216 E	NJ 216 E	NUP 216 E	80	140	26	132	165	3800	4800	1.58
NU 2216 E	NJ 2216 E	NUP 2216 E	80	140	33	178	242	3800	4800	2.05
NU 316 E	NJ 316 E	NUP 316 E	80	170	39	245	282	3400	4300	4.05
NU 2316	NJ 2316	NUP 2316	80	170	58	258	328	3400	4300	6.4
NU 416	NJ 416	NUP 416	80	200	48	285	315	3000	3800	8.3
NU 1017	NJ 1017	—	85	130	22	64.5	81.6	4000	5000	1.05
NU 217 E	NJ 217 E	NUP 217 E	85	150	28	158	192	3600	4500	2
NU 2217 E	NJ 2217 E	NUP 2217 E	85	150	36	205	272	3600	4500	2.58
NU 317 E	NJ 317 E	NUP 317 E	85	180	41	280	332	3200	4000	4.82
NU 2317	NJ 2317	NUP 2317	85	180	60	295	380	3200	4000	7.4
NU 417	NJ 417	NUP 417	85	210	52	312	345	2800	3600	9.8
NU 1018	NJ 1018	—	90	140	24	74	94.8	3800	4800	1.36
NU 218 E	NJ 218 E	NUP 218 E	90	160	30	172	215	3400	4300	2.44
NU 2218 E	NJ 2218 E	NUP 2218 E	90	160	40	230	312	3400	4300	3.26
NU 318 E	NJ 318 E	NUP 318 E	90	190	43	298	348	3000	3800	5.59
NU 2318	NJ 2318	NUP 2318	90	190	64	310	385	3000	3800	8.4
NU 418	NJ 418	NUP 418	90	225	54	352	392	2400	3200	11
NU 1019	NJ 1019	—	95	145	24	75.5	98.5	3600	4500	1.4
NU 219 E	NJ 219 E	NUP 219 E	95	170	32	208	262	3200	4000	2.96
NU 2219 E	NJ 2219 E	NUP 2219 E	95	170	43	275	368	3200	4000	3.97
NU 319 E	NJ 319 E	NUP 319 E	95	200	45	315	380	2800	3600	6.52
NU 2319	NJ 2319	NUP 2319	95	200	67	370	500	2800	3600	10.4
NU 419	NJ 419	NUP 419	95	240	55	378	428	3000	3000	14
NU 1020	NJ 1020	—	100	150	24	78	102	3400	4300	1.5
NU 220 E	NJ 220 E	NUP 220 E	100	180	34	235	302	3000	3800	3.58
NU 2220 E	NJ 2220 E	NUP 2220 E	100	180	46	318	440	3000	3800	4.86
NU 320 E	NJ 320 E	NUP 320 E	100	215	47	365	425	2600	3200	7.89
NU 2320	NJ 2320	NUP 2320	100	215	73	415	558	2600	3200	13.5
NU 420	NJ 420	NUP 420	100	250	58	418	480	2000	2800	16
NU 1021	NJ 1021	—	105	160	26	91.5	122	3200	4000	1.9
NU 221	NJ 221	NUP 221	105	190	36	185	235	2800	3600	4
NU 321	NJ 321	NUP 321	105	225	49	322	392	2200	3000	—
NU 421	NJ 421	NUP 421	105	260	60	508	602	1900	2600	—
NU 1022	NJ 1022	—	110	170	28	115	155	3000	3800	2.3
NU 222 E	NJ 222 E	NUP 222 E	110	200	38	278	360	2600	3400	5.02
NU 2222 E	NJ 2222 E	NUP 2222 E	110	200	53	318	445	2600	3400	7.5
NU 322	NJ 322	NUP 322	110	240	50	352	482	2000	2800	11
NU 2322	NJ 2322	NUP 2322	110	240	80	535	740	2000	2800	17.5
NU 422	NJ 422	NUP 422	110	280	65	515	602	1800	2400	22
NU 1024	NJ 1024	—	120	180	28	130	168	2600	3400	2.96
NU 224 E	NJ 224 E	NUP 224 E	120	215	40	322	422	2200	3000	6.11
NU 2224	NJ 2224	NUP 2224	120	215	58	345	522	2200	3000	9.5
NU 324	NJ 324	NUP 324	120	260	55	440	552	1900	2600	14
NU 2324	NJ 2324	NUP 2324	120	260	86	632	868	1900	2600	22.5
NU 424	NJ 424	NUP 424	120	310	72	642	772	1700	2200	30
NU 1026	NJ 1026	—	130	200	33	151	211	2400	3200	3.7
NU 226	NJ 226	NUP 226	130	230	40	258	352	2000	2800	7
NU 2226	NJ 2226	NUP 2226	130	230	64	368	552	2000	2800	11.5
NU 326	NJ 326	NUP 326	130	280	58	492	620	1700	2200	18
NU 2326	NJ 2326	NUP 2326	130	280	93	748	1060	1700	2200	28.5
NU 426	NJ 426	NUP 426	130	340	78	782	942	1500	1900	39
NU 1028	NJ 1028	—	140	210	33	158	220	2000	2800	4
NU 228	NJ 228	NUP 228	140	250	42	302	415	1800	2400	9.1
NU 2228	NJ 2228	NUP 2228	140	250	68	438	700	1800	2400	15
NU 328	NJ 328	NUP 328	140	300	62	545	690	1600	2000	22
NU 2328	NJ 2328	NUP 2328	140	300	102	805	1180	1600	2000	37
NU 428	NJ 428	NUP 428	140	360	82	845	1020	1400	1800	—
NU 1030	NJ 1030	—	150	225	35	188	262	1900	2600	4.8
NU 230	NJ 230	NUP 230	150	270	45	360	490	1700	2200	11
NU 2230	NJ 2230	NUP 2230	150	270	73	530	772	1700	2200	17
NU 330	NJ 330	NUP 330	150	320	65	595	765	1500	1900	26
NU 2330	NJ 2330	NUP 2330	150	320	108	930	1340	1500	1900	45
NU 430	NJ 430	NUP 430	150	380	85	912	1100	1300	1700	53
NU 1032	NJ 1032	—	160	240	38	212	302	1800	2400	6
NU 232	NJ 232	NUP 232	160	290	48	405	552	1600	2000	14
NU 2232	NJ 2232	NUP 2232	160	290	80	590	898	1600	2000	25
NU 332	NJ 332	NUP 332	160	340	68	628	825	1400	1800	31.6
NU 2332	NJ 2332	NUP 2332	160	340	114	972	1430	1400	1800	55.8
NU 1034	NJ 1034	—	170	260	42	255	365	1700	2200	8.14
NU 234	NJ 234	NUP 234	170	310	52	425	650	1500	1900	17.1
NU 334	NJ 334	NUP 334	170	360	72	715	952	1300	1700	36
NU 2334	NJ 2334	NUP 2334	170	360	120	1110	1650	1300	1700	63
NU 1036	NJ 1036	—	180	280	46	300	438	1600	2000	10.1
NU 236	NJ 236	NUP 236	180	320	52	425	650	1400	1800	18
NU 336	NJ 336	NUP 336	180	380	75	835	1100	1200	1600	42
NU 2336	NJ 2336	NUP 2336	180	380	126	1210	1780	1200	1600	71.2
NU 1038	NJ 1038	—	190	290	46	335	495	1500	1900	—
NU 238	NJ 238	NUP 238	190	340	55	512	745	1300	1700	23
NU 2238	NJ 2238	NUP 2238	190	340	92	975	1570	1300	1700	38.5
NU 338	NJ 338	NUP 338	190	400	78	882	1190	1100	1500	50
NU 1040	NJ 1040	—	200	310	51	408	615	1400	1800	14.3
NU 240	NJ 240	NUP 240	200	360	58	570	842	1200	1600	26
NU 2240	NJ 2240	NUP 2240	200	360	98	1120	1725	1200	1600	—
NU 340	NJ 340	NUP 340	200	420	80	972	1290	1000	1400	—
NU 1044	NJ 1044	—	220	340	56	448	685	1200	1600	—
NU 244	NJ 244	NUP 244	220	400	65	702	1050	1000	1400	36
NU 2244	NJ 2244	NUP 2244	220	400	108	1360	2330	1000	1400	62
NU 344	NJ 344	—	220	460	88	1080	1465	900	1200	75
NU 1048	NJ 1048	—	240	360	56	470	745	1000	1400	21
NU 248	NJ 248	NUP 248	240	440	72	880	1345	900	1200	48.2
NU 348	NJ 348	—	240	500	95	1290	1810	800	1000	97.1
NU 1052	NJ 1052	—	260	400	65	592	932	950	1300	31
NU 1056	NJ 1056	—	280	420	65	600	965	850	1100	33
NU 1060	NJ 1060	—	300	460	74	880	1470	800	1000	44.4
NU 260	NJ 260	—	300	540	85	1360	2190	700	900	87.2
NU 1064	NJ 1064	—	320	480	74	890	1520	750	950	47
NU 1080	NJ 1080	—	400	600	90	1420	2480	560	700	88.8

N, NF, NH Series

N Type Bearing Number	NF Type Bearing Number	NH Type Bearing Number	Bore Diameter d (mm)	Outside Diameter D (mm)	Bearing Width B (mm)	Basic Dynamic Load Rating Cr (kN)	Basic Static Load Rating Cor (kN)	Limiting Speed with Grease Lubrication (r/min)	Limiting Speed with Oil Lubrication (r/min)	Approximate Mass W (kg)
N 202	NF 202	—	15	35	11	7.98	5.5	15000	19000	—
N 203	NF 203	—	17	40	12	9.12	7	14000	18000	—
N 1004	—	—	20	42	12	10.5	8	13000	17000	0.09
—	NF 204	NJ 204 + HJ 204	20	47	14	12.5	11	12000	16000	0.11
N 204 E	—	—	20	47	14	25.8	24	12000	16000	0.117
N 2204 E	—	—	20	47	18	30.8	30	12000	16000	0.149
—	NF 304	NJ 304 + HJ 304	20	52	15	18	15.5	11000	15000	0.17
N 304 E	—	—	20	52	15	29	25.5	11000	15000	0.155
N 2304 E	—	—	20	52	21	39.2	37.5	10000	14000	0.216
N 1005	—	—	25	47	12	11	10.2	11000	15000	0.1
—	NF 205	NJ 205 + HJ 205	25	52	15	14.2	12.8	11000	14000	0.16
N 205 E	—	—	25	52	15	27.5	26.8	11000	14000	0.14
—	—	NJ 2205 + HJ 2205	25	52	18	21.2	19.8	11000	14000	—
N 2205 E	—	—	25	52	18	32.8	33.8	11000	14000	0.168
—	NF 305	NJ 305 + HJ 305	25	62	17	25.5	22.5	9000	12000	0.2
N 305 E	—	—	25	62	17	38.5	35.8	9000	12000	0.251
—	NF 2305	—	25	62	24	38.5	39.2	9000	12000	—
N 2305 E	—	—	25	62	24	53.2	54.5	9000	12000	0.355
—	NF 206	NJ 206 + HJ 206	30	62	16	19.5	18.2	8500	11000	0.2
N 206 E	—	—	30	62	16	36	35.5	8500	11000	0.214
—	—	NJ 2206 + HJ 2206	30	62	20	28.8	30.2	8500	11000	0.29
N 2206 E	—	—	30	62	20	45.5	48	8500	11000	0.268
—	NF 306	NJ 306 + HJ 306	30	72	19	33.5	31.5	8000	10000	0.3
N 306 E	—	—	30	72	19	49.2	48.2	8000	10000	0.377
—	NF 2306	—	30	72	27	46.5	47.5	8000	10000	0.6
N 2306 E	—	—	30	72	27	70	75.5	8000	10000	0.538
N 406	—	NJ 406 + HJ 406	30	90	23	57.2	53	7000	9000	0.73
—	NF 207	NJ 207 + HJ 207	35	72	17	28.5	28	7500	9500	0.3
N 207 E	—	—	35	72	17	46.5	48	7500	9500	0.311
—	—	NJ 2207 + HJ 2207	35	72	23	43.8	48.5	7500	9500	0.45
N 2207 E	—	—	35	72	23	57.5	63	7500	9500	0.414
—	NF 307	NJ 307 + HJ 307	35	80	21	41	39.2	7000	9000	0.56
N 307 E	—	—	35	80	21	62	63.2	7000	9000	0.501
—	NF 2307	—	35	80	31	54.8	57	7000	9000	0.85
N 2307 E	—	—	35	80	31	87.5	98.2	7000	9000	0.738
N 407	—	NJ 407 + HJ 407	35	100	25	70.8	68.2	6000	7500	0.94
N 1008	—	—	40	68	15	21.2	22	7500	9500	0.22
—	NF 208	NJ 208 + HJ 208	40	80	18	37.5	38.2	7000	9000	0.4
N 208 E	—	—	40	80	18	51.5	53	7000	9000	0.394
—	—	NJ 2208 + HJ 2208	40	80	23	52	57.8	7000	9000	0.53
N 2208 E	—	—	40	80	23	67.5	75.2	7000	9000	0.507
—	NF 308	NJ 308 + HJ 308	40	90	23	48.8	47.5	6300	8000	0.7
N 308 E	—	—	40	90	23	76.8	77.8	6300	8000	0.68
—	NF 2308	—	40	90	33	70.8	76.8	6300	8000	1.1
N 2308 E	—	—	40	90	33	105	118	6300	8000	0.974
N 408	—	NJ 408 + HJ 408	40	110	27	90.5	89.8	5600	7000	1.25
—	NF 209	NJ 209 + HJ 209	45	85	19	39.8	41	6300	8000	0.5
N 209 E	—	—	45	85	19	58.5	63.8	6300	8000	0.45
—	—	NJ 2209 + HJ 2209	45	85	23	54.8	62.2	6300	8000	0.59
N 2209 E	—	—	45	85	23	71	82	6300	8000	0.55
—	NF 309	NJ 309 + HJ 309	45	100	25	66.8	66.8	5600	7000	0.9
N 309 E	—	—	45	100	25	93	98	5600	7000	0.93
—	NF 2309	—	45	100	36	91.5	100	5600	7000	1.5
N 2309 E	—	—	45	100	36	130	152	5600	7000	1.34
N 409	—	NJ 409 + HJ 409	45	120	29	102	100	5000	6300	1.8
N 1010	—	—	50	80	16	25	27.5	6300	8000	—
—	NF 210	NJ 210 + HJ 210	50	90	20	43.2	48.5	6000	7500	0.6
N 210 E	—	—	50	90	20	61.2	69.2	6000	7500	0.505
—	—	NJ 2210 + HJ 2210	50	90	23	57.2	69.2	6000	7500	0.65
N 2210 E	—	—	50	90	23	74.2	88.8	6000	7500	0.59
—	NF 310	NJ 310 + HJ 310	50	110	27	76	79.5	5300	6700	1.2
N 310 E	—	—	50	110	27	105	112	5300	6700	1.2
—	NF 2310	NJ 2310 + HJ 2310	50	110	40	112	132	5300	6700	1.85
N 2310 E	—	—	50	110	40	155	185	5300	6700	1.79
N 410	—	NJ 410 + HJ 410	50	130	31	120	120	4800	6000	2.3
N 1011	—	—	55	90	18	35.8	40	5600	7000	0.45
—	NF 211	NJ 211 + HJ 211	55	100	21	52.8	60.2	5300	6700	0.7
N 211 E	—	—	55	100	21	80.2	95.5	5300	6700	0.68
—	—	NJ 2211 + HJ 2211	55	100	25	70.8	87.5	5300	6700	0.86
N 2211 E	—	—	55	100	25	94.8	118	5300	6700	0.81
—	NF 311	NJ 311 + HJ 311	55	120	29	97.8	105	4800	6000	1.7
N 311 E	—	—	55	120	29	128	138	4800	6000	1.53
—	NF 2311	NJ 2311 + HJ 2311	55	120	43	130	148	4800	6000	2.4
N 2311 E	—	—	55	120	43	190	228	4800	6000	2.28
N 411	—	NJ 411 + HJ 411	55	140	33	128	132	4300	5300	2.8
N 1012	—	—	60	95	18	38.5	45	5300	6700	0.48
—	NF 212	NJ 212 + HJ 212	60	110	22	62.8	73.5	5000	6300	0.9
N 212 E	—	—	60	110	22	89.8	102	5000	6300	0.86
—	—	NJ 2212 + HJ 2212	60	110	28	91.2	118	5000	6300	1.25
N 2212 E	—	—	60	110	28	122	152	5000	6300	1.12
—	NF 312	NJ 312 + HJ 312	60	130	31	118	128	4500	5600	2
N 312 E	—	—	60	130	31	142	155	4500	5600	1.87
—	NF 2312	NJ 2312 + HJ 2312	60	130	46	155	195	4500	5600	2
N 2312 E	—	—	60	130	46	212	260	4500	5600	2.81
N 412	—	NJ 412 + HJ 412	60	150	35	155	162	4000	5000	3.4
—	NF 213	NJ 213 + HJ 213	65	120	23	73.2	87.5	4500	5600	1.1
N 213 E	—	—	65	120	23	102	118	4500	5600	1.08
—	—	NJ 2213 + HJ 2213	65	120	31	108	145	4500	5600	—
N 2213 E	—	—	65	120	31	142	180	4500	5600	1.48
—	NF 313	NJ 313 + HJ 313	65	140	33	125	135	4000	5000	2.5
N 313 E	—	—	65	140	33	170	188	4000	5000	2.31
—	NF 2313	NJ 2313 + HJ 2313	65	140	48	175	210	4000	5000	4
N 2313 E	—	—	65	140	48	235	285	4000	5000	3.34
N 413	—	NJ 413 + HJ 413	65	160	37	170	178	3800	4800	4
N 1014	—	—	70	110	20	47.5	57	4800	6000	0.71
—	NF 214	NJ 214 + HJ 214	70	125	24	73.2	87.5	4300	5300	1.3
N 214 E	—	—	70	125	24	112	135	4300	5300	1.2
—	—	NJ 2214 + HJ 2214	70	125	31	108	145	4300	5300	1.7
N 2214 E	—	—	70	125	31	148	192	4300	5300	1.56
—	NF 314	NJ 314 + HJ 314	70	150	35	145	162	3800	4800	3.1
N 314 E	—	—	70	150	35	195	220	3800	4800	2.86
—	NF 2314	NJ 2314 + HJ 2314	70	150	51	212	260	3800	4800	4.4
N 2314 E	—	—	70	150	51	260	320	3800	4800	4.1
N 414	—	NJ 414 + HJ 414	70	180	42	215	232	3400	4300	5.9
—	NF 215	NJ 215 + HJ 215	75	130	25	89	110	4000	5000	1.4
N 215 E	—	—	75	130	25	125	155	4000	5000	1.32
—	—	NJ 2215 + HJ 2215	75	130	31	125	165	4000	5000	1.8
N 2215 E	—	—	75	130	31	155	205	4000	5000	1.64
—	NF 315	NJ 315 + HJ 315	75	160	37	165	188	3600	4500	3.7
N 315 E	—	—	75	160	37	228	260	3600	4500	3.43
N 2315	NF 2315	NJ 2315 + HJ 2315	75	160	55	245	308	3600	4500	5.4
N 415	—	NJ 415 + HJ 415	75	190	45	250	272	3200	4000	7.1
N 1016	—	—	80	125	22	59.2	77.8	4300	5300	1
—	NF 216	NJ 216 + HJ 216	80	140	26	102	125	3800	4800	1.7
N 216 E	—	—	80	140	26	132	165	3800	4800	1.58
—	—	NJ 2216 + HJ 2216	80	140	33	145	195	3800	4800	2.2
N 2216 E	—	—	80	140	33	178	242	3800	4800	2.05
—	NF 316	NJ 316 + HJ 316	80	170	39	175	200	3400	4300	4.4
N 316 E	—	—	80	170	39	245	282	3400	4300	4.05
N 2316	NF 2316	NJ 2316 + HJ 2316	80	170	58	258	328	3400	4300	6.4
N 416	—	NJ 416 + HJ 416	80	200	48	285	315	3000	3800	8.3
—	NF 217	NJ 217 + HJ 217	85	150	28	115	145	3600	4500	2.1
N 217 E	—	—	85	150	28	158	192	3600	4500	2
—	—	NJ 2217 + HJ 2217	85	150	36	165	230	3600	4500	2.8
N 2217 E	—	—	85	150	36	205	272	3600	4500	2.58
—	NF 317	NJ 317 + HJ 317	85	180	41	212	242	3200	4000	5.2
N 317 E	—	—	85	180	41	280	332	3200	4000	4.82
N 2317	NF 2317	NJ 2317 + HJ 2317	85	180	60	295	380	3200	4000	7.4
N 417	—	NJ 417 + HJ 417	85	210	52	312	345	2800	3600	9.8
N 1018	—	—	90	140	24	74	94.8	3800	4800	1.36
—	NF 218	NJ 218 + HJ 218	90	160	30	142	178	3400	4300	2.5
N 218 E	—	—	90	160	30	172	215	3400	4300	2.44
—	—	NJ 2218 + HJ 2218	90	160	40	192	268	3400	4300	3.5
N 2218 E	—	—	90	160	40	230	312	3400	4300	3.26
—	NF 318	NJ 318 + HJ 318	90	190	43	228	265	3000	3800	6.1
N 318 E	—	—	90	190	43	298	348	3000	3800	5.59
N 2318	NF 2318	NJ 2318 + HJ 2318	90	190	64	310	395	3000	3800	8.4
N 418	—	NJ 418 + HJ 418	90	225	54	352	392	2400	3200	11
—	NF 219	NJ 219 + HJ 219	95	170	32	152	190	3200	4000	3.2
N 219 E	—	—	95	170	32	208	262	3200	4000	2.96
—	—	NJ 2219 + HJ 2219	95	170	43	215	298	3200	4000	4.5
N 2219 E	—	—	95	170	43	275	368	3200	4000	3.97
—	NF 319	NJ 319 + HJ 319	95	200	45	245	288	2800	3600	7
N 319 E	—	—	95	200	45	315	380	2800	3600	6.52
N 2319	NF 2319	NJ 2319 + HJ 2319	95	200	67	370	500	2800	3600	10.4
N 419	—	NJ 419 + HJ 419	95	240	55	378	428	2200	3000	14
N 1020	—	—	100	150	24	78	102	3400	4300	1.5
—	NF 220	NJ 220 + HJ 220	100	180	34	168	212	3000	3800	3.5
N 220 E	—	—	100	180	34	235	302	3000	3800	3.58
—	—	NJ 2220 + HJ 2220	100	180	46	240	335	3000	3800	5.2
N 2220 E	—	—	100	180	46	318	440	3000	3800	4.86
—	NF 320	NJ 320 + HJ 320	100	215	47	282	340	2600	3200	8.6
N 320 E	—	—	100	215	47	365	425	2600	3200	7.89
N 2320	NF 2320	NJ 2320 + HJ 2320	100	215	73	415	558	2600	3200	13.5
N 420	—	NJ 420 + HJ 420	100	250	58	418	480	2000	2800	16
N 1021	—	—	105	160	26	91.5	122	3200	4200	1.9
N 221	NF 221	NJ 221 + HJ 221	105	190	36	185	235	2800	3600	4
N 321	NF 321	NJ 321 + HJ 321	105	225	49	322	392	2200	3000	—
N 421	—	NJ 421 + HJ 421	105	260	60	508	602	1900	2600	—
N 1022	—	—	110	170	28	115	155	3000	3800	2.3
—	NF 222	NJ 222 + HJ 222	110	200	38	220	285	2600	3400	5
N 222 E	—	—	110	200	38	278	360	2600	3400	5.02
N 2222	NF 2222	NJ 2222 + HJ 2222	110	200	53	312	445	2600	3400	7.5
N 322	NF 322	NJ 322 + HJ 322	110	240	50	352	428	2000	2800	11
N 2322	NF 2322	NJ 2322 + HJ 2322	110	240	80	535	740	2000	2800	17.5
N 422	—	NJ 422 + HJ 422	110	280	65	515	602	1800	2400	22
N 1024	—	—	120	180	28	130	168	2600	3400	2.96
—	NF 224	NJ 224 + HJ 224	120	215	40	230	332	2200	3000	6.4
N 224 E	—	—	120	215	40	322	422	2200	3000	6.11
N 2224	—	NJ 2224 + HJ 2224	120	215	58	345	522	2200	3000	9.5
N 324	NF 324	NJ 324 + HJ 324	120	260	55	440	552	1900	2600	14
N 2324	NF 2324	NJ 2324 + HJ 2324	120	260	86	632	868	1900	2600	22.5
N 424	—	NJ 424 + HJ 424	120	310	72	642	772	1700	2200	30
N 1026	—	—	130	200	33	152	212	2400	3200	3.7
N 226	NF 226	NJ 226 + HJ 226	130	230	40	258	352	2000	2800	7
N 2226	NF 2226	NJ 2226 + HJ 2226	130	230	64	368	552	2000	2800	11.5
N 326	NF 326	NJ 326 + HJ 326	130	280	58	492	620	1700	2200	18
N 2326	NF 2326	NJ 2326 + HJ 2326	130	280	93	748	1060	1700	2200	28.5
N 426	—	NJ 426 + HJ 426	130	340	78	782	942	1500	1900	39
N 1028	—	—	140	210	33	158	220	2000	2800	4
N 228	NF 228	NJ 228 + HJ 228	140	250	42	302	415	1800	2400	9.1
N 2228	—	NJ 2228 + HJ 2228	140	250	68	438	700	1800	2400	15
N 328	NF 328	NJ 328 + HJ 328	140	300	62	545	690	1600	2000	22
N 2328	NF 2328	NJ 2328 + HJ 2328	140	300	102	825	1180	1600	2000	37
N 428	—	NJ 428 + HJ 428	140	360	82	845	1020	1400	1800	—
N 1030	—	—	150	225	35	188	268	1900	2600	4.8
N 230	NF 230	NJ 230 + HJ 230	150	270	45	360	490	1700	2200	11
N 2230	NF 2230	NJ 2230 + HJ 2230	150	270	73	530	772	1700	2200	17
N 330	NF 330	NJ 330 + HJ 330	150	320	65	595	765	1500	1900	26
N 2330	NF 2330	NJ 2330 + HJ 2330	150	320	108	930	1340	1500	1900	45
N 430	—	NJ 430 + HJ 430	150	380	85	912	1100	1300	1700	53
N 1032	—	—	160	240	38	212	302	1800	2400	6
N 232	NF 232	NJ 232 + HJ 232	160	290	48	405	552	1600	2000	14
N 2232	—	NJ 2232 + HJ 2232	160	290	80	590	898	1600	2000	25
N 332	NF 332	NJ 332 + HJ 332	160	340	68	628	825	1400	1800	31.6
N 2332	NF 2332	—	160	340	114	972	1430	1400	1800	55.8
N 1034	—	—	170	260	42	255	365	1700	2200	8.14
N 234	NF 234	NJ 234 + HJ 234	170	310	52	425	650	1500	1900	17.1
N 334	—	—	170	360	72	715	952	1300	1700	36
N 2334	NF 2334	—	170	360	120	1110	1650	1300	1700	63
N 1036	—	—	180	280	46	300	438	1600	2000	10.1
N 236	—	NJ 236 + HJ 236	180	320	52	425	650	1400	1800	18
N 336	—	—	180	380	75	835	1100	1200	1600	42
N 2336	NF 2336	—	180	380	126	1210	1780	1200	1600	71.2
N 1038	—	—	190	290	46	335	495	1500	1900	10
N 238	—	NJ 238 + HJ 238	190	340	55	512	745	1300	1700	23
N 2238	—	NJ 2238 + HJ 2238	190	340	92	975	1570	1300	1700	38.5
N 338	—	—	190	400	78	882	1190	1100	1500	50
N 1040	—	—	200	310	51	408	615	1400	1800	14.3
N 240	—	NJ 240 + HJ 240	200	360	58	570	842	1200	1600	26
N 2240	—	NJ 2240 + HJ 2240	200	360	98	1120	1725	1200	1600	—
N 340	—	—	200	420	80	972	1290	1000	1400	—
N 1004	—	—	220	340	56	448	685	1200	1600	—
N 244	—	NJ 244 + HJ 244	220	400	65	702	1050	1000	1400	36
N 2244	—	—	220	400	108	1360	2330	1000	1400	62
N 1048	—	—	240	360	56	470	745	1000	1400	21
N 248	—	NJ 248 + HJ 248	240	440	72	880	1345	900	1200	48.2
N 348	—	—	240	500	95	1290	1810	800	1000	97.1
N 1052	—	—	260	400	65	592	932	950	1300	31
N 1056	—	—	280	420	65	600	965	850	1100	33
N 1060	—	—	300	460	74	880	1470	800	1000	44.4
N 260	—	—	300	540	85	1360	2190	700	900	87.2
N 1064	—	—	320	480	74	890	1520	750	950	47
N 1080	—	—	400	600	90	1420	2480	560	700	88.8

RNU Series –  Cylindrical Roller Bearing without Inner Ring Size Chart

RNU Type Bearing Number	Roller Set Bore Diameter Fw (mm)	Outside Diameter D (mm)	Bearing Width B (mm)	Basic Dynamic Load Rating Cr (kN)	Basic Static Load Rating Cor (kN)	Limiting Speed with Grease Lubrication (r/min)	Limiting Speed with Oil Lubrication (r/min)	Approximate Mass W (kg)
RNU 202	20	35	11	7.98	5.5	15000	19000	0.038
RNU 203	22.9	40	12	9.12	7	14000	18000	—
RNU 204 E	26.5	47	14	25.8	24	12000	16000	0.089
RNU 2204 E	26.5	47	18	30.8	30	12000	16000	0.113
RNU 304 E	27.5	52	15	29	25.5	11000	15000	0.12
RNU 2304 E	27.5	52	21	39.2	37.5	10000	14000	0.168
RNU 1005	30.5	47	12	11	10.2	11000	15000	—
RNU 205 E	31.5	52	15	27.5	26.8	11000	14000	0.104
RNU 2205 E	31.5	52	18	32.8	33.8	11000	14000	0.124
RNU 305 E	34	62	17	38.5	35.8	9000	12000	0.193
RNU 2305 E	34	62	24	53.2	54.5	9000	12000	0.272
RNU 206 E	37.5	62	16	36	35.5	8500	11000	0.159
RNU 2206 E	37.5	62	20	45.5	48	8500	11000	0.202
RNU 306 E	40.5	72	19	49.2	48.2	8000	10000	0.285
RNU 2306 E	40.5	72	27	70	75.5	8000	10000	0.409
RNU 207 E	44	72	17	46.5	48	7500	9500	0.233
RNU 2207 E	44	72	23	57.5	63	7500	9500	0.307
RNU 307 E	46.2	80	21	62	63.2	7000	9000	0.379
RNU 2307 E	46.2	80	31	87.5	98.2	7000	9000	0.557
RNU 208 E	49.5	80	18	51.5	53	7000	9000	0.294
RNU 2208 E	49.5	80	23	67.5	75.2	7000	9000	0.38
RNU 308 E	52	90	23	76.8	77.8	6300	8000	0.515
RNU 2308 E	52	90	33	105	118	6300	8000	0.738
RNU 209 E	54.5	85	19	58.5	63.8	6300	8000	0.335
RNU 2209 E	54.5	85	23	71	82	6300	8000	0.407
RNU 309 E	58.5	100	25	93	98	5600	7000	0.703
RNU 2309 E	58.5	100	36	130	152	5600	7000	1.01
RNU 210 E	59.5	90	20	61.2	69.2	6000	7500	0.369
RNU 2210 E	59.5	90	23	74.2	88.8	6000	7500	0.433
RNU 310 E	65	110	27	105	112	5300	6700	0.896
RNU 2310 E	65	110	40	155	185	5300	6700	1.34
RNU 211 E	66	100	21	80.2	95.5	5300	6700	0.508
RNU 2211 E	66	100	25	94.8	118	5300	6700	0.601
RNU 311 E	70.5	120	29	128	138	4800	6000	1.16
RNU 2311 E	70.5	120	43	190	228	4800	6000	1.74
RNU 212 E	72	110	22	89.8	102	5000	6300	0.632
RNU 2212 E	72	110	28	122	152	5000	6300	0.831
RNU 312 E	77	130	31	142	155	4500	5600	1.4
RNU 2312 E	77	130	46	212	260	4500	5600	2.12
RNU 213 E	78.5	120	23	102	118	4500	5600	0.796
RNU 2213 E	78.5	120	31	142	180	4500	5600	1.09
RNU 1014	80	110	20	47.5	57	4800	6000	—
RNU 313 E	82.5	140	33	170	188	4000	5000	1.75
RNU 2313 E	82.5	140	48	235	285	4000	5000	2.54
RNU 214 E	83.5	125	24	112	135	4300	5300	0.878
RNU 2214 E	83.5	125	31	148	192	4300	5300	1.15
RNU 215 E	88.5	130	25	125	155	4000	5000	0.964
RNU 2215 E	88.5	130	31	155	205	4000	5000	1.21
RNU 314 E	89	150	35	195	220	3800	4800	2.18
RNU 2314 E	89	150	51	260	320	3800	4800	3.11
RNU 315 E	95	160	37	228	260	3600	4500	2.62
RNU 216 E	95.3	140	26	132	165	3800	4800	1.14
RNU 2216 E	95.3	140	33	178	242	3800	4800	1.49
RNU 2315	95.5	160	55	245	308	3600	4500	4.54
RNU 1017	96.5	130	22	64.5	81.6	4000	5000	0.72
RNU 217 E	100.5	150	28	158	192	3600	4500	1.48
RNU 2217 E	100.5	150	36	205	272	3600	4500	1.93
RNU 316 E	101	170	39	245	282	3400	4300	3.1
RNU 1018	103	140	24	74	94.8	3800	4800	0.98
RNU 218 E	107	160	30	172	215	3400	4300	1.79
RNU 2218 E	107	160	40	230	312	3400	4300	2.41
RNU 317 E	108	180	41	280	332	3200	4000	3.66
RNU 2317	108	180	60	295	380	3200	4000	6.47
RNU 219 E	112.5	170	32	208	262	3200	4000	2.22
RNU 2219 E	112.5	170	43	275	368	3200	4000	2.97
RNU 318 E	113.5	190	43	298	348	3000	3800	4.27
RNU 220 E	119	180	34	235	302	3000	3800	2.68
RNU 2220 E	119	180	46	318	440	3000	3800	3.65
RNU 319 E	121.5	200	45	315	380	2800	3600	4.86
RNU 1022	125	170	28	115	155	3000	3800	1.91
RNU 320 E	127.5	215	47	365	425	2600	3200	5.98
RNU 222 E	132.5	200	38	278	360	2600	3400	3.69
RNU 1024	135	180	28	130	168	2600	3400	2.31
RNU 321	135	225	49	322	392	2200	3000	—
RNU 322	143	240	50	352	428	2000	2800	—
RNU 224 E	143.5	215	40	322	422	2200	3000	4.52
RNU 324	154	260	55	440	552	1900	2600	—
RNU 226	156	230	40	258	352	2000	2800	5.6
RNU 1028	158	210	33	158	220	2000	2800	—
RNU 326	167	280	58	492	620	1700	2200	—
RNU 228	169	250	42	302	415	1800	2400	—
RNU 1030	169.5	225	35	188	268	1900	2600	3.64
RNU 328	180	300	62	545	690	1600	2000	—
RNU 230	182	270	45	360	490	1700	2200	—
RNU 330	193	320	65	595	765	1500	1900	—
RNU 232	195	290	48	405	552	1600	2000	—
RNU 1036	205	280	46	300	438	1600	2000	—
RNU 332	208	340	68	628	825	1400	1800	—
RNU 234	208	310	52	425	650	1500	1900	—
RNU 236	218	320	52	425	650	1400	2800	—
RNU 334	220	360	72	715	952	1300	1700	—
RNU 238	231	340	55	512	745	1300	1700	—
RNU 336	232	380	75	835	1100	1200	1600	—
RNU 240	244	360	58	570	842	1200	1600	—
RNU 338	245	400	78	882	1190	1100	1500	—
RNU 340	260	420	80	972	1290	1000	1400	—
RNU 244	270	400	65	702	1050	1000	1400	—

RN Series – Cylindrical Roller Bearing without Outer Ring Size Chart

RN Type Bearing Number	Bore Diameter d (mm)	Roller Set Outside Diameter Ew (mm)	Bearing Width B (mm)	Basic Dynamic Load Rating Cr (kN)	Basic Static Load Rating Cor (kN)	Limiting Speed with Grease Lubrication (r/min)	Limiting Speed with Oil Lubrication (r/min)	Approximate Mass W (kg)
RN 204 E	20	41.5	14	25.8	24	12000	16000	—
RN 2204 E	20	41.5	18	30.8	30	12000	16000	—
RN 304 E	20	45.5	15	29	25.5	11000	15000	—
RN 2304 E	20	45.5	21	39.2	37.5	10000	14000	—
RN 205 E	25	46.5	15	27.5	26.8	11000	14000	—
RN 2205 E	25	46.5	18	32.8	33.8	11000	14000	—
RN 305 E	25	54	17	38.5	35.8	9000	12000	—
RN 2305 E	25	54	24	53.2	54.5	9000	12000	—
RN 206 E	30	55.5	16	36	35.5	8500	11000	—
RN 2206 E	30	55.5	20	45	48	8500	11000	—
RN 306 E	30	62.5	19	49.2	48.2	8000	10000	—
RN 2306 E	30	62.5	27	70	75.5	8000	10000	—
RN 207 E	35	64	17	46.5	48	7500	9500	—
RN 2307 E	35	64	23	57.5	63	7500	9500	—
RN 307 E	35	70.2	21	62	63.2	7000	9000	—
RN 2307 E	35	70.2	31	87.5	98.2	7000	9000	—
RN 407	35	83	25	70.8	68.2	6000	7500	0.64
RN 208 E	40	71.5	18	51.5	53	7000	9000	—
RN 2308 E	40	71.5	23	67.5	75.2	7000	9000	—
RN 308 E	40	80	23	76.8	77.8	6300	8000	—
RN 2308 E	40	80	33	105	118	6300	8000	—
RN 408	40	92	27	90.5	89.8	5600	7000	—
RN 209 E	45	76.5	19	58.5	63.8	6300	8000	—
RN 2209 E	45	76.5	23	71	82	6300	8000	—
RN 309 E	45	88.5	25	93	98	5600	7000	—
RN 2309 E	45	88.5	36	130	152	5600	7000	—
RN 1010	50	72.5	16	25	27.5	6300	8000	—
RN 210 E	50	81.5	20	61.2	69.6	6000	7500	—
RN 2210 E	50	81.5	23	74.2	88.8	6000	7500	—
RN 310 E	50	97	27	105	112	5300	6700	—
RN 2310 E	50	97	40	155	185	5300	6700	—
RN 211 E	55	90	21	80.2	95.5	5300	6700	—
RN 2211 E	55	90	25	94.8	118	5300	6700	—
RN 311 E	55	106.5	29	128	138	4800	6000	—
RN 2311 E	55	106.5	43	190	228	4800	6000	—
RN 1012	60	86.5	18	38.5	45	5300	6700	0.303
RN 212 E	60	100	22	89.8	102	5000	6300	—
RN 2212 E	60	100	28	122	152	5000	6300	—
RN 312	60	115	31	142	155	4500	5600	—
RN 2312 E	60	115	46	212	260	4500	5600	—
RN 213 E	65	108.5	23	102	118	4500	5600	—
RN 2213 E	65	108.5	31	142	180	4500	5600	—
RN 313 E	65	124.5	33	170	188	4000	5000	—
RN 2313 E	65	124.5	48	235	285	4000	5000	—
RN 1014	70	100	20	47.5	57	4800	6000	—
RN 214 E	70	113.5	24	112	135	4300	5300	—
RN 2214 E	70	113.5	31	148	192	4300	5300	—
RN 314 E	70	133	35	195	220	3800	4800	—
RN 2314 E	70	133	51	260	320	3800	4800	—
RN 215 E	75	118.5	25	125	155	4000	5000	—
RN 2215 E	75	118.5	31	155	205	4000	5000	—
RN 315 E	75	143	37	228	260	3600	4500	—
RN 216 E	80	127.5	26	132	165	3800	4800	—
RN 2216 E	80	127.5	33	178	242	3800	4800	—
RN 316 E	80	151	39	245	282	3400	4300	—
RN 217 E	85	136.5	28	158	192	3600	4500	—
RN 2217 E	85	136.5	36	205	272	3600	4500	—
RN 317 E	85	160	41	280	332	3200	4000	—
RN 218 E	90	145	30	172	215	3400	4300	—
RN 2218 E	90	145	40	230	312	3400	4300	—
RN 318 E	90	169.5	43	298	348	3000	3800	—
RN 219 E	95	154.5	32	208	262	3200	4000	—
RN 2219 E	95	154.5	43	275	368	3200	4000	—
RN 319 E	95	177.5	45	315	380	2800	3600	—
RN 220 E	100	163	34	235	302	3000	3800	—
RN 2220 E	100	163	46	318	440	3000	3800	—
RN 320 E	100	191.5	47	365	425	2600	3200	—
RN 221	105	168.8	36	185	235	2800	3600	2.76
RN 321	105	195	49	322	392	2200	3000	—
RN 222 E	110	180.5	38	278	360	2600	3400	—
RN 322	110	207	50	352	428	2000	2800	—
RN 224 E	120	195.5	40	322	422	2200	3000	—
RN 324	120	226	55	440	552	1900	2600	—
RN 226	130	204	40	258	352	2000	2800	4.48
RN 326	130	243	58	492	620	1700	2200	—
RN 228	140	221	42	302	415	1800	2400	5.94
RN 328	140	260	62	545	690	1600	2000	13.2
RN 230	150	238	45	360	490	1700	2200	—
RN 330	150	277	65	595	765	1500	1900	17.04
RN 232	160	255	48	405	552	1600	2000	—
RN 332	160	292	68	628	825	1400	1800	—
RN 234	170	272	52	425	650	1500	1900	—
RN 334	170	310	72	715	952	1300	1700	—
RN 236	180	282	52	425	650	1400	1800	—
RN 336	180	328	75	835	1100	1200	1600	35.9
RN 238	190	299	55	512	745	1300	1700	—
RN 338	190	345	78	882	1190	1100	1500	31.6
RN 240	200	316	58	570	842	1200	1600	—
RN 340	200	360	80	972	1290	1000	1400	—
RN 244	220	350	65	702	1050	1000	1400	—

Part 2. Double Row Cylindrical Roller Bearing Size Chart

NN Type Bearing Number	NN K Type Bearing Number	Bore Diameter d (mm)	Outside Diameter D (mm)	Bearing Width B (mm)	Basic Dynamic Load Rating Cr (kN)	Basic Static Load Rating Cor (kN)	Limiting Speed with Grease Lubrication (r/min)	Limiting Speed with Oil Lubrication (r/min)	Approximate Mass W (kg)
—	NN 3005 K	25	47	16	24.8	28.5	13000	16000	0.12
NN 3006	NN 3006 K	30	55	19	29.2	35.5	11000	14000	0.19
NN 3007	NN 3007 K	35	62	20	37.2	47.5	10000	13000	0.25
NN 3008	NN 3008 K	40	68	21	40.8	53.2	9000	12000	0.3
NN 3009	NN 3009 K	45	75	23	47.5	62.2	8000	10000	0.38
NN 3010/W33	NN 3010 K/W33	50	80	23	50.2	69.8	7500	9000	0.42
NN 3011/W33	NN 3011 K/W33	55	90	26	65.8	91.8	6700	8000	0.62
NN 3012/W33	NN 3012 K/W33	60	95	26	70	100	6300	7500	0.66
NN 3013/W33	NN 3013 K/W33	65	100	26	72.5	110	6000	7000	0.71
NN 3014/W33	NN 3014 K/W33	70	110	30	92	142	5300	6700	1
NN 3015/W33	NN 3015 K/W33	75	115	30	92	142	5000	6000	1.1
NN 3016/W33	NN 3016 K/W33	80	125	34	112	175	4800	5600	1.5
NN 3017/W33	NN 3017 K/W33	85	130	34	118	195	4500	5300	1.6
NN 3018/W33	NN 3018 K/W33	90	140	37	132	205	4300	5000	2
NN 3019/W33	NN 3019 K/W33	95	145	37	135	220	4000	4800	2.1
NNU 4920/W33	NNU 4920 K/W33	100	140	40	122	242	4000	4800	1.9
NN 3020/W33	NN 3020 K/W33	100	150	37	142	238	3800	4500	2.2
NNU 4921/W33	NNU 4921 K/W33	105	145	40	122	248	3800	4500	2
NN 3021/W33	NN 3021 K/W33	105	160	41	180	290	3600	4300	2.8
NNU 4922/W33	NNU 4922 K/W33	110	150	40	125	258	3800	4500	2.05
NN 3022/W33	NN 3022 K/W33	110	170	45	208	342	3400	4000	3.55
NNU 4924/W33	NNU 4924 K/W33	120	165	45	168	322	3400	4000	2.8
NN 3024/W33	NN 3024 K/W33	120	180	46	218	370	3200	3800	3.85
NNU 4926/W33	NNU 4926 K/W33	130	180	50	178	370	3000	3600	3.85
NN 3026/W33	NN 3026 K/W33	130	200	52	272	452	2800	3400	5.75
NNU 4928/W33	NNU 4928 K/W33	140	190	50	180	380	2800	3400	4.1
NN 3028/W33	NN 3028 K/W33	140	210	53	282	495	2600	3200	6.2
NNU 4930/W33	NNU 4930 K/W33	150	210	60	312	622	2600	3200	6.25
NN 3030/W33	NN 3030 K/W33	150	225	56	312	542	2400	3000	7.5
NNU 4932/W33	NNU 4932 K/W33	160	220	60	312	645	2400	3000	6.6
NN 3032/W33	NN 3032 K/W33	160	240	60	350	622	2200	2800	9.1
NNU 4934/W33	NNU 4934 K/W33	170	230	60	320	660	2200	2800	6.95
NN 3034/W33	NN 3034 K/W33	170	260	67	435	775	2000	2600	12.5
NNU 4936/W33	NNU 4936 K/W33	180	250	69	382	808	1900	2600	10.5
NN 3036/W33	NN 3036 K/W33	180	280	74	532	950	1900	2400	16.5
NNU 4938/W33	NNU 4938 K/W33	190	260	69	382	835	1800	2400	11
NN 3038/W33	NN 3038 K/W33	190	290	75	565	1030	1800	2400	17
NNU 4940/W33	NNU 4940 K/W33	200	280	80	460	988	1900	2400	15
NN 3040/W33	NN 3040 K/W33	200	310	82	612	1080	1800	2200	22
NNU 4944/W33	NNU 4944 K/W33	220	300	80	485	1080	1800	2200	17
NN 3044/W33	NN 3044 K/W33	220	340	90	768	1390	1700	2000	28.5
NNU 4948/W33	NNU 4948 K/W33	240	320	80	502	1060	1700	2000	17.5
NN 3048/W33	NN 3048 K/W33	240	360	92	800	1480	1500	1800	32
NNU 4952/W33	NNU 4952 K/W33	260	360	100	710	1620	1400	1700	30.5
NN 3052/W33	NN 3052 K/W33	260	400	104	970	1830	1300	1600	46
NNU 4956/W33	NNU 4956 K/W33	280	380	100	725	1710	1300	1600	32
NN 3056/W33	NN 3056 K/W33	280	420	106	1030	1980	1200	1500	49.5
NNU 4960/W33	NNU 4960 K/W33	300	420	118	970	2240	1100	1000	50.9
NN 3060/W33	NN 3060 K/W33	300	460	118	1190	2280	900	1200	68.5
NNU 4964	NNU 4964 K	320	440	118	1455	3335	—	—	53
NN 3064	NN 3064 K	320	480	121	1760	3520	—	—	71
NNU 4968	NNU 4968 K	340	460	118	1500	3525	—	—	56
NN 3068/W33	NN 3068 K/W33	340	520	133	1570	3290	800	900	97.5
NNU 4972	NNU 4972 K	360	480	118	1540	3715	—	—	58.5
NN 3072/W33	NN 3072 K/W33	360	540	134	1630	4380	700	800	105
NNU 4976	NNU 4976 K	380	520	140	1980	4695	—	—	83.5
NN 3076/W33	NN 3076 K/W33	380	560	135	1600	3280	600	700	110
NNU 4980	NNU 4980 K	400	540	140	2030	4920	—	—	87.5
NN 3080	NN 3080 K	400	600	148	2620	5380	—	—	135
NNU 4984	NNU 4984 K	420	560	140	2075	5145	—	—	91
NN 3084	NN 3084 K	420	620	150	2710	5695	—	—	140
NNU 4988	NNU 4988 K	440	600	160	2550	6205	—	—	120
NN 3088	NN 3088 K	440	650	157	2955	6250	—	—	165
NNU 4992	NNU 4992 K	460	620	160	2605	6460	—	—	130
NN 3092/W33	NN 3092 K/W33	460	680	163	2470	5230	450	560	195
NNU 4996	NNU 4996 K	480	650	170	2890	7175	—	—	154
NN 3096	NN 3096 K	480	700	165	3290	7135	—	—	193
NNU 49/500	NNU 49/500 K	500	670	170	2950	7450	—	—	158
NN 30/500	NN 30/500 K	500	720	167	3390	7490	—	—	210
NNU 49/530	NNU 49/530 K	530	710	180	3280	8360	—	—	190
NN 30/530	NN 30/530 K	530	780	185	4070	8855	—	—	260
NNU 49/560	NNU 49/560 K	560	750	190	3625	9320	—	—	225
NN 30/560/W33	NN 30/560 K/W33	560	820	195	2460	6560	340	430	319
NNU 49/600	NNU 49/600 K	600	800	200	4020	10500	—	—	257
NN 30/600	NN 30/600 K	600	870	200	4805	10785	—	—	340
NNU 49/630	NNU 49/630 K	630	850	218	4655	12600	—	—	340
NN 30/630	NN 30/630 K	630	920	212	5370	12035	—	—	415
NNU 49/670	NNU 49/670 K	670	900	230	5135	13515	—	—	390
NN 30/670/W33	NN 30/670 K/W33	670	980	230	4620	9360	220	300	560

Part 3. Four Row Cylindrical Roller Bearing Size Chart

FC / FCDP / FCD Type Bearing Number	Bore Diameter d (mm)	Outside Diameter D (mm)	Bearing Width B (mm)	Roller Set Bore Diameter Fw (mm)	Chamfer Radius r Min (mm)	Chamfer Radius r1 Min (mm)	Basic Dynamic Load Rating Cr (kN)	Basic Static Load Rating Cor (kN)
FC 2028104	100	140	104	111	1.5	1.1	395	925
FC 202970	100	145	70	113	1.5	1.1	218	432
FC 2234120	110	170	120	127	2	2	605	1060
FC 2436105	120	180	105	135	2	2	550	1145
FC 2640104	130	200	104	149	2	2	620	1240
FC 2640125	130	200	125	149	2	2	738	1220
FC 2842116	140	210	116	160	2	2	700	1475
FC 2842125	140	210	125	158	2	2	622	1270
FC 2842155	140	210	155	158	2	2	786	1710
FC 2942155	145	210	155	166	2	2	855	2020
FC 2945156	145	225	156	169	2	2	975	2080
FC 3045120	150	225	120	169	2	2	788	1290
FC 3046156	150	230	156	174	2	2	990	2145
FC 3246130	160	230	130	180	2.1	2.1	815	1865
FC 3248168	160	240	168	183	2.1	2.1	942	1950
FC 3248124	160	240	124	183	2.1	2.1	690	1310
FC 3450170	170	250	170	192	2.1	2.1	1070	2080
FC 3452120	170	260	120	196	2.1	2.1	648	1020
FC 3652168	180	260	168	202	2.1	2.1	1145	2715
FC 3656180	180	280	180	207	2.1	2.1	1460	2340
FC 3852168	190	260	168	212	2.1	2.1	1085	2815
FC 3854200	190	270	200	212	2.1	2.1	1360	3395
FC 4056200	200	280	200	222	2.1	2.1	1340	3375
FC 4058192	200	290	192	226	2.1	2.1	1430	3450
FC 4260210	210	300	210	234	2.1	2.1	1540	3400
FC 4462192	220	310	192	246	2.1	2.1	1230	3120
FC 4464210	220	320	210	248	2.1	2.1	1510	3330
FC 4666206	230	330	206	260	2.1	2.1	1350	3510
FC 4668260	230	340	260	261	2.1	2.1	2000	4400
FC 4866220	240	330	220	270	2.1	2.1	1735	4665
FC 4872220	240	360	220	272	2.1	2.1	2070	4800
FC 5070220	250	350	220	278	3	3	1885	4885
FC 5274220	260	370	220	292	3	3	2030	5110
FC 5276280	260	380	280	294	3	3	2580	6560
FC 5476230	270	380	230	298	3	3	2140	4750
FC 5678220	280	390	220	312	3	3	2105	5465
FC 5684280	280	420	280	319	4	4	2930	7130
FC 5882240	290	410	240	320	4	4	2470	5330
FC 5884300	290	420	300	327	4	4	3010	7815
FC 6084218	300	420	218	332	4	4	1980	4680
FC 6084240	300	420	240	332	4	4	2170	5280
FCD 6084300	300	420	300	332	3	3	2920	7370
FC 6490240	320	450	240	355	—	—	2220	5320
FC 6496290	320	480	290	364	4	4	2980	5980
FCD 6496350	320	480	350	364	4	4	3970	8320
FC 6692340	330	460	340	365	4	4	3300	9140
FC 6892260	340	460	260	370	4	4	2650	7000
FCD 6896350	340	480	350	378	4	4	3570	9560
FCD 72102370	360	510	370	392	4	4	4040	10000
FCD 76108400	380	540	400	422	4	4	4930	12200
FCD 80112410	400	560	410	445	5	5	4480	13100
FCD 84120440	420	600	440	470	5	5	5450	14800
FCD 88124450	440	620	450	487	5	5	6060	16000
FCD 92130470	460	650	470	509	5	5	6890	17800
FCD 96130450	480	650	450	525	6	6	5710	18100
FCD 96136500	480	680	500	532	6	6	7220	18900
FCD 100144530	500	720	530	568	6	6	6180	19900
FCD 106156570	530	780	570	601	6	6	8630	22300
FCD 112164630	560	820	630	625	6	6	12500	28300
FCDP 114163594	570	815	594	628	6	6	12200	28200
FCDP 120164575	600	820	575	660	6	6	9340	31400
FCDP 120174640	600	870	640	682	6	6	10400	33800
FCDP 126180670	630	900	670	698	6	6	15900	41400
FCDP 134190700	670	950	700	750	7.5	7.5	13100	41900
FCDP 142200715	710	1000	715	787.5	7.5	7.5	15000	44800
FCDP 150200670	750	1000	670	813	7.5	7.5	13800	47800
FCDP 160216700	800	1080	700	878	7.5	7.5	14000	52200
FCDP 160230850	800	1150	850	905	7.5	7.5	17900	62400
FCDP 170230840	850	1150	840	928	7.5	7.5	20100	70400
FCD 180244840	900	1220	840	989	7.5	7.5	19500	74400
FCDP 1902721000	950	1360	1000	1075	7.5	7.5	22900	82400
FCDP 200272800	1000	1360	800	1101	7.5	7.5	18700	67300

Also Read: Needle Roller Bearing Size Chart: Drawn Cup, Machined Ring, Thrust, Combined, etc

Part 4. FAQS About Cylindrical Roller Bearing Size Chart

Final Words

With this cylindrical roller bearing size chart, you can quickly check common bearing numbers, dimensions, load ratings, limiting speeds, and related technical data. However, the size chart is only for reference. If you need to buy cylindrical roller bearings or replace an old bearing, or cannot find the model you need in the chart,  please contact BKZ Industry with your bearing number, size, drawing, or application requirements. As an ISO 9001 certified bearing manufacturer with 2 factories, BKZ Industry can help you confirm the suitable cylindrical roller bearing and offer reliable bulk supply.
